1) Single channel output
2) Front / behind output terminal
3) Internal radiator and electronic temperature control cooling
4) Digital or pointer meter display output voltage and output current
5) Current-limiting protection and users can set the current-liming protection point arbitrarily
6) Reverse polarity protection
7) Voltage Output: 0-30V
8) Current Output: 0-5A
9) Input voltage AC 220V± 10% 50Hz/60Hz (also can be AC 110V± 10% 50Hz/60Hz if required )
10) Working Condition Temperature: -10-40Degree Celsius Relative humidity: <90%
11) Storage Condition Temperature: -10-40Degree Celsius Relative humidity: <80%
12) Constant Voltage Operation Voltage stability: ≤ 0.01%+2mV
13) Load stability: ≤ 0.01%+2mV
14) Recovery time: ≤ 100uS
15) Ripple and noise: ≤ 1mVrms ( effective value )
16) Temperature coefficient: ≤ 200PPM/Degree Celsius
17) Constant Current Operation Current stability: ≤ 0.1%+3mA
18) Load stability: ≤ 0.2%+3mA
19) Ripple and noise: ≤ 2mArms ( effective value )
20) Voltage Display Precision 4 digits LED display: ± 1%
21) Current Display Precision 4 digits LED display: ± 1%
22) Size: 275 x 155 x 126mm
2) Front / behind output terminal
3) Internal radiator and electronic temperature control cooling
4) Digital or pointer meter display output voltage and output current
5) Current-limiting protection and users can set the current-liming protection point arbitrarily
6) Reverse polarity protection
7) Voltage Output: 0-30V
8) Current Output: 0-5A
9) Input voltage AC 220V± 10% 50Hz/60Hz (also can be AC 110V± 10% 50Hz/60Hz if required )
10) Working Condition Temperature: -10-40Degree Celsius Relative humidity: <90%
11) Storage Condition Temperature: -10-40Degree Celsius Relative humidity: <80%
12) Constant Voltage Operation Voltage stability: ≤ 0.01%+2mV
13) Load stability: ≤ 0.01%+2mV
14) Recovery time: ≤ 100uS
15) Ripple and noise: ≤ 1mVrms ( effective value )
16) Temperature coefficient: ≤ 200PPM/Degree Celsius
17) Constant Current Operation Current stability: ≤ 0.1%+3mA
18) Load stability: ≤ 0.2%+3mA
19) Ripple and noise: ≤ 2mArms ( effective value )
20) Voltage Display Precision 4 digits LED display: ± 1%
21) Current Display Precision 4 digits LED display: ± 1%
22) Size: 275 x 155 x 126mm
Specification:
| Package Weight |
|
